6
Pair of buttons for flat control with EnOcean module
Hooking the pair of buttons 20506-19506-14506 onto the flat control with two radio rocker push buttons 20505.
Pair of buttons 20506 -19506-14506
Flat control 20505
Pair of buttons hooked onto the flat control 20505
Installation on flush mounting box
Mounting frame 21612-19612-14612
Cover plate 20652.. - 20682.. - 19652.. - 19682.. - 14652..
The distance from flush with the wall mounting frame +
cover plate + control + buttons is 9.5 mm for Eikon, 10.2
mm for Arkè and 10.5 mm for Plana.
Warning: Installation can be performed also on mounting
frames with 3, 4 and 7 modules art. 21613-19613-14613,
21614-19614-14614 and 21617-19617-14617) and rela-
ted cover plates.
