Pair of buttons for flat control with EnOcean module
Surface-mounting installation.
Mounting frame 21507 - 20507 - 19507
Cover plate 20652.. - 20682.. - 19652..-
19682.. - 14652..
The distance mounting frame + cover plate + control + buttons
is 13 mm for Eikon, 13.7 mm for Arkè and 14 mm for Plana.
Installation on BS flush mounting box.
Mounting frame 20607-14607
Cover plate 20647.. - 20677.. - 14647..
