Description
Wall-mount Tab 7 monitor for Due Fili Plus system with 7" LCD colour display, loudspeaker for calls, capaci-
tive keypad for entryphone functions (unlocking, self-starting, auxiliary services, volume, brightness and con-
trast controls) and intercom calls.
Desktop installation is possible with the desktop base accessory 40195 (sold separately).
Can be used by wearers of hearing aids.
Audio frequency function for hearing aids
The video entryphone can be used by people wearing hearing aids.
For correct functioning of the hearing aid, please refer to its instruction manual. Any metal objects or electronic
equipment in the vicinity may affect the quality of the sound received by the hearing aid.
Technical characteristics
• Wall-mounted, with metal bracket, in box: circular 2M (Vimar V71701), 3M (Vimar V71303, V71703) hori-
zontal and vertical, 4+4M (Vimar V71318, V71718) and square, British standard.
• 7" LCD 16:9 display, resolution 800x480 pixels
• Minimum video signal level on the bus for reception: -20 dBm
• Capacitive touch keypad with backlit symbols.
• Powered from BUS terminals 1, 2 - nominal voltage 28Vdc
• Power consumption:
- in standby: 25 mA
- maximum current: 350 mA
• Ambient class: Class A1 (indoor use)
• IP30 protection rating
• Electronic ringer with 10 different melodies.
• Input for landing call.
• Dimensions: 165.8 x 184 x 24.2 mm
• DIP switch for line termination impedance.
Maintenance
Clean using a soft cloth. Do not pour water onto the appliance and do not use any type of chemical product.
Cleaning must be carried out either with the apparatus powered off (= disconnected from the bus) or after acti-
vating the keypad cleaning procedure (see the relative paragraph).
Warnings for the user
Do not open or tamper with the appliance.
In the event of faults, contact specialized personnel.
