Mounting points
The plate can be mounted using a 3-module flush-mounted
back box (horizontal or vertical) or with pressure plugs.
INSTALLATION
- Install the monitor away from sources of light and heat.
- Fig. 1 - Fix the monitor mounting plate to the wall with a
distance of about 1.4 m between the bottom edge and the
ground (Fig. 5).
- Make the connections on the monitor terminal block.
- Fit the monitor following the direction of arrows 1 and 2 (Fig.
6).
1,40
Fig. 5
1
1
1
2
2
1
Fig. 6
Fig. 7
10
EN
6329, 6329/C, 6329/CD
