22
K40945 - K40946 - K40955 - K40956
Schema di collegamento impian-
to bifamiliare con due targhe e
no a tre monitor per utente
Schéma de connexion instal-
lation deux usagers avec deux
plaques et jusqu'à trois moni-
teurs par usager
Esquema de conexión de una
instalación bifamiliar con dos
placas y hasta tres monitores
por usuario
Esquema de ligação do sistema
bifamiliar com duas botoneiras e
até três monitores por utilizador
Schaltbild einer Zweifamilien
-
anlage mit zwei Klingeltableaus
und bis zu drei Monitoren pro
Benutzer
Διάγραμμα σύνδεσης εγκα
-
τάστασης δύο οικογενειών με
δύο μπουτονιέρες και έως τρεις
οθόνες ανά χρήστη
Two-family system connection
diagram with two panels and up
to three monitors per user
-
+
Lock
automatic door
BUS1+
BUS1-
COM
NO/NC
BUS2+
BUS2-
LOCK
GND
CCTV GND
24V
OS2
OS1GND
Red Black
24V OS2OS1GND
Red Black
automatic door
BUS1+
BUS1-
COM
NO/NC
BUS2+
BUS2-
LOCK
GND
CCTV GND
POWER
-
+
POWER
Lock
Famiglia 1 - Family 1 - Famille 1 - Familie 1 -
Familia 1 - Família 1 - Οικογένεια 1
40945.M - ID: Master
Famiglia 2 - Family 2 - Famille 2 - Familie 2 -
Familia 2 - Família 2 - Οικογένεια 2
40945.M - ID: Master
