3. Control panel description (Fig. 1):
Legend:
1- Mains connection terminal
2- Removable terminal for connection of control inputs and safety devices
3- Quick-release motor and encoder connecting terminal
4- Terminal for aerial connection
5- Terminal for connecting the warning light for gate open or safety device test
6- Terminal for blinker connection
7- Terminal for electric motor connection
8- Terminal for motor capacitor connection
9- Step-step push button
10- Travel programming push button
11- Remote control programming push button
12- Trimmer for motor force adjustment
13- Configuration DIP-switch
14- Fuse F1 T3.15A 5 x 20 mm protecting the power supply unit and motor line
15- Power signalling LED
16- LED cluster signalling input status
17- Magnetic sensor for limit switch 1
18- Magnetic sensor for limit switch 2
4. Connection to the mains electricity (fig. 2):
Terminal no. Terminal markings Description
N N
Neutral connection
Earth connection
F F
Live connection
5. Accessories connection (fig. 3):
Terminal no. Description
18-22
Input for activating step-step button (NO contact)
18 - N.O. contact
22 - common
19-22
Photocell input when opening (NC contact)
19 - NC contact
22 - common
Note:
jumper if not used
20-22
Photocell input (NC contact)
20 - NC contact
22 - common
Note:
jumper if not used
21-22
Input for stopping button (NO contact)
61 - NC contact
22 - common
Note:
jumper if not used
22-23
Power supply output for accessories (24 Vdc, max 300 mA)
22 - negative
23 - positive
9-10 Flashing light power supply output 230 Vac, max 100 W
16-17
Antenna connection
16 - signal
17 - earth
Safety device connections
To connect 1 or 2 pairs of photocells with closing not checked see fig. 4a and fig. 4b
To connect 1 or 2 pairs of photocells with opening not checked see fig. 5a and fig. 5b
To connect a NC safety edge see fig. 6
To connect photocells with opening and closing checked see Fig. 7
The external photocell (terminal 20) is ignored in the opening phase, it commands immediate reopening during the closing phase.
The internal photocell (terminal 19, DIP6 = OFF) stops the gate upon engagement, on disengagement it continues opening if in the opening phase, and it
commands reopening on disengagement if in the closing phase.
The safety edge (terminal 19, DIP6 = ON) stops the gate and closes by approx. 10 cm when opening, it commands total reopening when closing.
