10
ACTO
EN
DIP Function
Position Function
DIP1
Close immediately
OFF Close immediately function off
ON
Closes on completing opening with a pre-flash of 2 sec., after an engagement and disengagement of the
external photocell (terminal 20), regardless of the set pause time
DIP2 Automatic closing
OFF Automatic closing off
ON Automatic closing on
DIP3 Step-step button logic
OFF
Operation of the step-step button (terminal 18) and the remote control with 2 step logic:
open-close-open
ON
Operation of the step-step button (terminal 18) and the remote control with 4 step logic:
open-stop-close-stop-open
DIP4 Apartment block OFF Apartment block function off
ON
Apartment block function on:
During opening, the step-step button (terminal 18) and the remote control are ignored.
During the pause time the step-step button (terminal 18) and the remote control reset the pause. If the au-
tomatic closure is not on, with the door completely open the step-step button (terminal 18) and the remote
control command the closure
DIP5 Slowdown distance
OFF The slowdown starts at 90% of the door travel (minimum slowdown space)
ON The slowdown starts at 80% of the door travel (maximum slowdown space)
DIP6 Input 63 operation
OFF Input terminal 19 as internal photocell (for the executed function see sub-section 5)
ON Input terminal 19 as safety edge (for the executed function see sub-section 5)
DIP7 Actuator type
OFF Operation for ESM8 (ACTO 510A) for 500 kg gates
ON Operation for ESM9 (ACTO 810A) for 800 kg gates
DIP8 Photocell test
OFF Tests on inputs 19 and 20 disabled
ON Tests on inputs 19 and 20 enabled
6. DIP-switch functions
7. Trimmer function
Trimmer Function
POWER
Motor force adjustment:
Turning clockwise increases the force (the obstacle sensitivity decreases)
Turning anticlockwise decreases the force (the obstacle sensitivity increases)
If an obstacle is detected:
When closing:
- after the first 4 interventions without completing a manoeuvre: it fully reopens.
- after the 5th intervention without completing a manoeuvre:
it disengages (stop and reverse for 1 sec.) and goes into stop mode (does not close automatically)
When opening:
- it disengages (stops and reverses for 1 sec.)
8. Button functions
Button Card marking Print on card cover Function
P/P P/P Step-step push button
PROG PROG P1 Travel programming button
MEMO RX MEMO RX P2 Remote control programming button
9. Travel programming:
N.B.: Do not change the wiring of the electric motor, the control panel is configured by default to open the gate to the right, to reverse the opening
direction follow the procedure described below in the table
Pressing button Flashing message Effect
PROG (P1) On
Move the gate to about 1 metre from completely closed, press and hold the PROG (P1) push button until
the flashing light comes on, release the PROG (P1) push button.
The control panel goes into travel programming mode for 2 min. After 2 min. with no intervention by the
installer, the control panel exits the travel programming mode.
P/P On
Press and release the P/P button, the gate must close at reduced speed. If instead it opens, do not
change the wiring of the electric motor but press the PROG (P1) push button to reverse the direction.
The flashing light stays on
- On
As soon as it reaches the CLOSING limit switch, the automation system starts opening at reduced speed
until the OPENING limit switch trips and the flashing light stays on
P/P On
From the moment the gate stops due to the opening limit switch tripping, the control panel saves the total
travel of the gate and starts counting the automatic closing time (maximum time 250 seconds), once the
required time has elapsed, press button P/P; the automation system will start to close at normal speed
- Off
The gate slows down and then stops when the closing limit switch trips, exiting programming and the
flashing light switches off.
Note:
The first closing and first opening are performed at slowdown speed, any change in the DIP-switches or POWER trimmer must
be made when the gate is stationary.
