Disconnect the wires from the old thermostat one by one, you may
need a screwdriver to release wires from terminals. Unscrew and
take off the mounting plate of your old thermostat from the wall.
· You can choose to use the trim plate which comes along with your thermostat. The trim plate is
useful if you want to hide marks or holes left on the wall of your old thermostat.
· If the trim plate is to be used, then align the mounting holes on the trim plate and wall plate and
press them together
· Pull the wires trough the hole in the middle of the wall plate and attach the wall plate to the wall
using the screws sets(screw& anchor) to mount the new wall plate. Be sure to check the alignment
of your wall plate before and after the wall plate installation.
Note: Wrap the wires around a pen or pencil so they don’t fall back.
Disconnect the wires and remove the old wall plate
Step 6
Mount the new wall plate
Step 7
07
