Safety - Read This First!
Warning symbols in this maintenance manual
Where there is a risk of personal injury, injury to others, or damage to the pedestal or
associated equipment, comments appear, highlighted by the word WARNING! and
supported by the warning triangle symbol.
Warning symbols on the pedestal
On encountering the warning triangle and open book symbols it is imperative that you
consult this maintenance manual before using this pedestal or attempting any adjustment or
repair.
Critical data
Mass
Column 6 kg (13 lb)
Skid 5.5 kg (12 lb)
Load
Maximum Load 20 kg (44 lb)
Pressure
Maximum Pressure 9.6 bar (140 psi)
≤20 KG
6 KG
≤9.6 BAR
5.5
