15
Parts list
The following lists include main assemblies, user-replaceable spare parts and optional accesso-
ries. For further information regarding repair or spare parts, please contact Vinten Broadcast Ltd
or your local distributor.
For information on-line, visit our website at
www.vinten.com.
Main assemblies
Vision 3 pan and tilt head 3543-3
Bowl clamp knob assembly 3330-30
Pan bar and clamp 3219-78
Camera mounting plate, with 3/8 in. BSF screws and VHS pin adaptor 3449-900SP
VHS pin adaptor 3330-29
User-replaceable spare parts
Brake knob kit 3431-900SP
Battery (‘N’ type) C550-024
Balance spring kits, comprising spring, spring cover plate and instructions:
Spring strength 1 (silver) U005-161
Spring strength 2 (grey) U005-162
Spring strength 5 (green) U005-165
Spring strength 8 (red) U005-168
Spring strength 9 (black) U005-169
Spring strength 10 (yellow) U005-170
Optional accessories - Quickfit adaptors
ENG Quickfit Automatic Adaptor (with wedge plate) 3371-3
Quickfit wedge 3763-11
Optional accessories - tripod and pedestal adaptors
75 mm ball to 100 mm bowl adaptor U005-159
