Setting the pan and tilt brakes
17 Both the PAN BRAKE and TILT BRAKE are fully applied when the respective lever on the left hand side
of the head is rotated fully clockwise.
Operation
18 With the PAN BRAKE, TILT BRAKE applied and the CENTRE LOCK engaged, adjust the position of
the pan bar to suit the operators requirements by slackening the wing headed stud and moving the pan bar
and quadrant to the desired position. Retighten the wing headed stud.
19 While firmly holding the pan bar withdraw the tilt CENTRE LOCK control knob and set the PAN BRAKE
and TILT BRAKE to the off position.
20 Check the freedom of movement in both pan and tilt axes and adjust the drag on each by means of the
PAN DRAG and TILT DRAG control knobs to suit, the operator.
21 The PAN BRAKE and TILT BRAKE must be applied if the camera is to be left on a static shot for any
period of time with the operator in control to prevent inadvertent movement.
22 If the camera is to be left unattended the PAN BRAKE and TILT BRAKE must be applied and the tilt
CENTRE LOCK engaged.
WARNING!: The tilt centre lock must be engaged and the pan and tilt brakes must be
applied before any attempt is made to fit or remove any equipment mounted on the pan
and tilt head.
NOTE: Repositioning of the pan bars may necessitate fine adjustment in the fore and aft position
of the camera and of the balance.
