4 – 23
Use the , , , and (POSITION) keys to move the cutter pen to alignment point 2 (any point on
the X-axis for the previously plotted medium). The coordinates displayed here indicate the distance from
alignment point 1.
Press the (ENTER) key to calculate the X-axis angle of inclination and align the axes.
Press the (PAUSE) key to cancel PAUSE mode.
Step
5
Step
6
Step
7
After the axes are aligned, the settings will be reset if any of the following are per-
formed.
• Specification of a new origin
• Loading of a new medium
• Setting of the axis rotation
PT2 0, 0
CHECKPOINT
