6
Introduction
2. Rear View
1). Headphone out
: Connect it to your headphone or audio equipments.
4).
3).
RF
: Connect antenna or cable 75 Ohm coaxial to receive TV signal.
11).
COAX : Digital audio output.
10).
YPbPr : Connect them to the component video output of video device.
: Connect it to the HDMI output of video device.
7).
HDMI
: Connect to power supply with the mains adaptor.
8).
POWER
VIDEO : Connect it to video output of video device.
5).
L/R in
: Connect them to audio output of video device.
(Shared with YPbPr)
6).
9). Service
: For service use only.
2).
Coax
RF VGAPC-audio HDMI
Service
POWERVideo R in L in
YPbPr
1 2 3 4 5 6 7 8
9
10
11
