Byte Bit 7...0
11 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+1.4
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.5
n Bit 3: 0 (fix)
n Bit 4: ... input I+1.6
n Bit 5: 0 (fix)
n Bit 6: ... input I+1.7
n Bit 7: 0 (fix)
12 ... 15 reserved
