Viper TC-3 - Page 6

MODEL:
COMPONENT
DESCRIPTION
COMPONENT
MANUFACTURER
MFR’S PART NO. QUANTITY
1
Cover
tc3cov1
1
2
Set Phillips screw
tc3sps2
1
3
1/2 h.p. Motor
tc3mot3
1
4
Limit magnets
tc3lm4
2
5
Control board
tc3c/b5
1
6
Capacitor
tc3cap6
1
7
L-brackets
tc3lb7
2
8
Plastic clip
tc3pc8
4
9
Base plate for receiver/
limit switch sensor
tc3bp9
1
10
Base plate for control board
tc3bp10
1
11
Plastic clips
tc3pc11
4
12
Receiver
tc3rec12
1
13
Large bracket for magnet (open limit)
tc3lbol13
1
14
Small bracket for magnet (close limit)
tc3sbcl14
1
15
Chain bolts
tc3cb15
2
16
Spare nuts & bolts bag
tc3nb16
1
17
Mounting base
tc3mb17
1
18
Motor housing
tc3mh18
1
19
Limit switch sensor
tc3ls19
1
20
Manual release keys
tc3keys20
2
21
Shaft key
tc3sk21
1
22
Chain guard
tc3cg22
1
23
10 ft. chain
tc3ch23
1
24
U- bolts
tc3ub24
4
25
Square U-bolts
tc3sub25
4
5
