TC-9 Viper ™ Gate System
Residential Sliding Gate Operator
Description of your TC-9 Viper Gate Opener
FEATURES
Weather proof casing
Reliable magnetic limit switches for accurate open and close gate positions.
Self-locking gear motor in both o
pen and close positions.
Two channel 300 mhz receiver.
Auto-clos
e (12.5,25, and 45 second delay)
2 year limited warranty on motor
1 year limited warranty on manual & electric parts
SAFETY
Electric Safety monitor will stop and reverse gate to open position if it senses an
obstruction while gate is closing.
Release-key to open gate manually in case of an emergency (ie: power failure, fire, etc.).
Electronic anti-entrapment system, operable in both the open
and closing directions.
Enclosed chain cover for added protection.
SPECIFICATIONS
Table 1, Viper TC-9 Specification
Motor Safety
Type Permanent split
capacitor,
Personal Push button remote,
auto reversal
Speed 1470 RPM Electronic Independent up/down
force adjustment
Volts 120 VAC ± 10% 60 Hz Electrical Motor overload
protection
Current Less than 6 Amps Start Circuit 24 V push button or
remote sensor.
Operating Temp.
-22/158F (-30/70C)
Emergency Clutch release Key
Torque 15 N.m maximum
Drive Mechanism Dimension
Gears 1:30 Ratio Length (overall) N/A
Drive Chain gear type Ship Weight 58 lbs.
Length of Travel 35 ft max. by magnetic
Limit Switch
Chain Length 20 ft. (supplied), ANSI
chain No. 41
Travel Rate 1 ft per second. Gate Size 35 ft. (Maximum)
Gate Weight (max.) 1200 lbs. (Maximum)
