Vision Fitness Multi-Station Gym ST710 User Manual

18
I
J
K
L
Rubber
Spacers
H
M
8
STEP
NOTE: You will need to remove pulleys
H, I, J, K, L, and M to route cable #2.
• Route the loop only end of the cable
through the following pulleys in the specified
order: over pulley I, over J, under floating
pulley housing H, over K, under L, and
under M. Center the cable end loop
between the attachment points on the leg
curl post (AH2). Slide the shoulder bolt
(M8x16) through one side of the attachment
point, a rubber spacer, the cable eyelet, a
rubber spacer, and the other attachment
point. Attach a nut (M8). Tighten this and all
pulley bolts.
CABLE #2
