Vislink DR07 - Green Tally and Return Data Connections

User Manual Focal Point
Camera Control Interface Unit - CRIU-ASSY-7XXX
Issue No: M Page: 16
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Connector
25-WAY D-Type Socket
Pin
Signal
1
GND
2
Ch. 1. Green Dry
3
GND
4
Ch. 2. Green Dry
5
GND
6
Ch. 3. Green Dry
7
GND
8
Ch. 4. Green Dry
9
GND
10
Ch. 5. Green Dry
11
GND
12
Ch. 6. Green Dry
13
GND
14
Ch. 1. Green Wet A
15
Ch. 1. Green Wet B
16
Ch. 2. Green Wet A
17
Ch. 2. Green Wet B
18
Ch. 3. Green Wet A
19
Ch. 3. Green Wet B
20
Ch. 4. Green Wet A
21
Ch. 4. Green Wet B
22
Ch. 5. Green Wet A
23
Ch. 5. Green Wet B
24
Ch. 6. Green Wet A
25
Ch. 6. Green Wet B
Connector
7-Pin, 1-Key LEMO Socket
Pin
Signal
1
GND
2
TX D (From Unit)
3
RX D (Into Unit)
4
NC
5
NC
6
NC
7
NC
