Vislink DR07 - OCP Setup and Camera Selection

User Manual Focal Point
Camera Control Interface Unit - CRIU-ASSY-7XXX
Issue No: M Page: 18
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Frequency
xxx.xxxxx MHz
Power
X.XX W
OCP Setup
OCP Channel 1..6
Enabled
Yes/No
Camera ID
01..96
OCP
Sony
Hitachi
Panasonic
Panasonic PTZ
Ikegami OCP-100
Ikegami OCP-300
Ikegami OCP-399
OCP5
Grass Valley
Transparent
OCP Interface***
RS232 / RS422
Camera
HDC1500, HXC100,
HSC300, HDC-P1,
HDC2400, HDC1700,
HDC2500***
PMW-F55,
PDW-F800, PXW-
X500, PXW-X320,
PMW-500, PMW-
400, HDC4300, PDW-
700***
OTHER***
SK-HD1000, SK-
HD1200, SK-HD1500
***
DK-HD100 ***
PTZ AW-HE40,
PTZ AW-HE130***
