User Manual Focal Point
Data Receiver
Issue No: M Page: 41
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Connector
5-Pin, 1-Key LEMO Socket
Pin
Signal
1
RX-
2
RX+ (RS485/RS232RX)
3
TX+
4
TX- (RS485/RS232TX)
5
GND
Connector
6-Pin, 1-Key LEMO Socket
Pin
Signal
1
Red Tally Signal
2
12V Prot
3
Green Tally Signal
4
TTL TX (TTL CC Hitachi)
5
TTL RX (TTL CC Hitachi)
6
GND
Connector
2-Pin, 1-Key LEMO Socket
Pin
Signal
1
9-18V DC Input
2
0V
Connector
2-Pin, 1-Key LEMO Socket
Pin
Signal
1
GND
2
Data Out
