Camera Control Data Receiver Cables
Issue No: M Page: 57
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Vislink cable part number: DR07-ASSY-2012.
Data Receiver
Camera Connector
6-Pin LEMO Plug
FGG.0B.306.CLAD52Z
2-pin LEMO Plug
FGG.0B.302.CLAD52
4-Pin Hirose Plug
HR107P4P
Connector
Pin
Pin
6-Pin
1
NC
2
NC
3
NC
4
3
5
2
6
NC
2-Pin
1
1
2
4
Vislink cable part number: CCCU-ASSY-2034
Data Receiver
Camera Connector
5-Pin LEMO Plug
FGG.0B.305.CLAD52Z
8-Pin TAJIMI Plug
TAJIMI, PRC05-P8M
Pin
Pin
1
B
2
A
3
C
4
D
5
F
Vislink cable part number: DR07-ASSY-2016.
Data Receiver
Camera Connector
5-Pin LEMO Plug
FGG.0B.305.CLAD52Z
2-pin LEMO Plug
FGG.0B.302.CLAD52
8-Pin TAJIMI Plug
TAJIMI, PRC05-P8M
Connector
Pin
Pin
5-Pin
1
B
2
A
3
C
4
D
5
F
2-Pin
1
E
