When the OCP Channel Return Data is set to Yes an Auto Send All option is available. This
has an adjustable timer with settings from Off to 300 Seconds or any 30 second interval
between.
The Auto Send All operation timer starts its internal countdown when the FocalPoint
Interface Unit stops receiving Return Data (while the Wireless Camera system is switched
off). When the timer has completed its countdown, an automatic Send All (RU Paint
settings) is sent to the camera when the next Return Data packet is received (once the
Wireless Camera is switched on).
Two Interface Units can be configured to connect to each other over Ethernet. One
Interface unit should be assigned to the Data Transmitter(s) and the other to the OCP(s).
1. Set the Configuration input to Ethernet, using the following menus:
Configuration > Input: Ethernet
2. Set the Ethernet Port as required, using the following menus:
Ethernet Port > Configuration
3. Set the Ethernet Receive Port number to match the OCP(s) Interface Unit Transmit
Setup Port number, using the following menus:
Ethernet Port > Receive Setup > Port: XXXXX
4. Set the Destination IP and Port number as the OCP(s) Interface Unit, using the
following menus:
Ethernet Port > Transmit Setup:
Dest. IP: XXX.XXX.XXX.XXX
Port: XXX.XXX.XXX.XXX
