Vislink FCDT-ASSY-7002 User Manual

User Manual Focal Point
Operators Control Panel (OCP5) OCP5-ASSY-7XXX
Issue No: M Page: 46
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
NOTE: Tally_Dry assumes a closed pair of contacts and Tally_Wet assumes a 5VDC
(nominal) voltage in either polarity.
Connector
D-Type 9-Pin
Pin
Signal
1
PREVIEW_A
2
PREVIEW_B
3
NC
4
NC
5
TALLY_DRY_A (ground)
6
TALLY_DRY_B
7
TALLY_WET_A
8
TALLY_WET_B
9
GND
NOTE: The DC input is in conjunction with an internal fuse (alternative powering method,
see Section 6.1.3).
Connector
XLR 4-Pin
Pin
Signal
1
-ve / Ground
2
NC
3
NC
4
+12VDC
The USB/Ethernet port is dual purpose, as follows:
 Ethernet port for remote control and monitoring.
 USB port for unit software upgrade.
Connector
8-pin LEMO Connector EGG.1B.308.CLN
Pin
Signal
Function
1
TX+
Ethernet
2
TX-
3
RX+
4
RX-
5
0V GND
USB
6
USB_+
7
USB_-
8
+5V out
