Vislink FCDT-ASSY-7002 User Manual

User Manual Focal Point
Camera Control Interface to OCP/RCP Cables
Issue No: M Page: 61
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Vislink cable part number: RHD9-ASSY-2014
Camera Control Interface
OCP/RCP Connector
15-Way D-Type Plug
3-Pin XLR Plug
9-Way D-Type Socket
Connector
Pin
Pin
Connector
15-Way
1
1
9-Way
2
8
9-Way
3
7
9-Way
4
NC
-
5
NC
-
6
NC
-
7
NC
-
8
NC
-
9
NC
-
10
NC
-
11
5
9-Way
12
NC
-
13
NC
-
14
NC
-
15
NC
-
3-Pin
2
3
9-Way
3-Pin
3
4
9-Way
Vislink cable part number: RHD9-ASSY-2015
Camera Control Interface
OCP/RCP Connector
15-Way D-Type Plug
9-Way D-Type Plug
4-Pin XLR
Connector
Pin
Pin
Connector
15-Way
1
4
4Pin XLR
2
NC
-
3
2
9-Way
4
3
9-Way
5
NC
-
6
NC
-
7
NC
-
8
NC
-
9
NC
-
10
NC
-
11
1
4-Pin XLR
9
9-Way
12
NC
-
13
NC
-
14
NC
-
15
NC
-
