UltraReceiver User Manual
Main Display
Issue No: 3 Page: 16
Ref: ULRX-ASUM-700X Copyright © 2018 Vislink plc
Here you configure the input for decoding.
Here the PID’s of each parameter of the service must be entered for correct decoding.
Here the Audio format of the service must be entered for correct decoding.
Here the Video format of the service must be entered for correct decoding. Note there is
no function or up or down scaling so the format must be that of the encoder.
Controls the mode of operation of the video synchronization.
OFF, uses the Transport stream PCR to maintain timing.
ON (external) uses tri-level or composite sync to provide the timing reference.
NOTE: Using ON (external) adds 40ms delay to the system.
ON (internal) references the video to an internal oscillator.
When ON, the line & pixel offsets are adjustable.
The line number is adjustable between 0 and 1080. For negative offsets use values
between 0 and 540, for positive offsets use the formula, 1124 – the offset required as the
front panel value.
NOTE: The “lock” status displays and can take 10 seconds to complete.
