These menus display useful information if you need to contact the Vislink. In particular, the
versions of the various modules in the unit.
The unit can display detailed information on the performance of the unit.
Pre- & post-Viterbi errors: TPS & FEC Lock, Downconverter currents & SELF TEST
results.
Video Lock, TS lock, Frame Lock, Chroma and GOP formats. In h.264 and Generic
MPEG2 modes, also displays picture format information.
Temperatures (in some modes).
Table 5-4 Diagnostics Menu Overview
NOTE: Contact us about availability of this option.
The below table shows the entire menu structure for HCAM. Your system may not display
all menu options. Some menu options are context sensitive, depending on your current
configuration. Some menu options may be license dependent.
NOTE: When “..” shows in between two values, it indicates the value available. For
instance, “Service 1..4” means there are four services to select from.
To Next Page
