5. COMPLIANCE WITH STANDARDS
The MC-302V PG2 complies with the following standards:
Europe: EN300220, EN301489 EN50130-4, EN61000-6-3, EN60950-1, EN50131-1, EN50131-2-6 and
EN50131-6 Type C.
Certified by Norwegian accredited certification body Applica Test & Certification AS in accordance with
EN50131-1, EN50131- 2-6, EN50131-6, EN50130-4 et EN50130-5
Hereby, Visonic Ltd. declares that the radio equipment type MC-302V PG2 is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
http://www.visonic.com/download-center.
USA: FCC - CFR 47 part 15, UL - UL-634
Canada: IC - RSS 210, ULC - ULC C634
The Power G peripheral devices have two- way communication functionality, providing additional benefits as
described in the technical brochure. This functionality has not been tested to comply with the respective
technical requirements and should therefore be considered outside the scope of the product’s certification.
Security Grade Designed according to EN 50131-1, EN-50131-2-6 and EN-50131-6 Type C: this equipment can be applied
in installed systems up to and including Security Grade 2.
Environmental Class EN-50131-2-6 Class II
FCC Compliance Statement
The digital circuitry of this device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and
television reception. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause such
interference, which can be verified by turning the device off and on, the user is encouraged to eliminate the interference by one or more of the following
measures:
l Re-orient or re-locate the receiving antenna.
l Increase the distance between the device and the receiver.
l Connect the device to an outlet on a circuit different from the one that supplies power to the receiver.
l Consult the dealer or an experienced radio/TV technician.
Warning! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
This device complies with FCC Rules Part 15 and with Industry Canada licence-exempt RSS standard(s). Operation is subject to two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference that may be received or that may cause undesired
operation.
Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisee aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique
subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement.
Reed Switch Positions
Wood Supports Iron
Opening Closing Direction Opening Closing
>14 mm >12 mm X* <12 mm >9 mm
>22 mm >20 mm Y** <11 mm >9 mm
>30 mm >27 mm Z*** <12 mm >9 mm
* X axis The distance between the edge of the sensor to the edge
of the magnet in the X axis direction.
**Y axis The distance between A to B in the Y axis direction.
***Z axis The distance between the sensor and the magnet from
the plane defined by the Z axis direction.
Figure 4: Range Coverage Directions
D-304535 MC-302V PG2 Installation Instructions 3
