Visonic POWERMAX+ Easy Start Guide

Trigger a tamper on the sensor, trigger the input (for universal
•
or aux input on door contacts) or press button (for hand held
devices) to initiate a transmission.
Remove battery from transmitter, press
•
, then to
enrol an additional device.
If a sensor has already been enrolled in another zone a long L
error tone will be heard and the sensor will not be accepted
again.
PIR’s have back tampers which require both the front and L
back tamper switch to be pressed simultaneously during
enrolling.
6) Dening the Zone Types will allow you to program what
happens when alarm sensors are triggered in the armed Away &
Home modes, whilst also being able to allocate a zone name and
chime setting. This section is only used for the Movement Sensor
and Door Contact.
You should be in the installer mode, press
until [Zone
Denitions] is shown. Press , and enter the zone number
you need to program followed by again.
At the screen Zone Type press
and the existing setting will
be shown, press to scroll to the next option then press
and again once you nd the zone type required.
Interior—This zone will be turned off during the Home set
•
(ideal for Landing and bedroom detectors).
Interior Follower—This zone will allow access in the delay
•
mode (without triggering the alarm), and will also be turned
off during the Home set mode (Ideal for Hall sensors that
need to be off during the night).
Perimeter—This zone will trigger during the Away and Home
•
mode (ideal for Living rooms, Kitchens etc).
Perimeter Follower—Same as above but allows access through
•
the detector during the delay mode (ideal for Hallways).
Delay 1 & 2—These zones will start an entry timer when
•
activated during the Away or Home mode (ideal for the
front and back door which are being used as entry and exit
points).
Note: There are many more zone types. Please refer to the L
installation manual for more information.
The next screen allows you to pick the [Zone Name]. As previously,
press
to enter the menu then press to scroll through
the library until you nd the name required then press and
again to conrm.
Finally, press
to enter the chime option and select whether
you would like this to be Off, Melody or Zone name type.
7) The diagnostic testing feature is a useful tool for
determining the signal strength from the sensors deployed on
site. This should be carried out before and after you have installed
the system.
Whilst in installer mode main menu :-
Press
•
until the screen shows ‘Diagnostics’, then press
.
Press
•
again (to test sensors) and ‘Diag. Testing’ will be
on screen.
Now walk around the premises and trigger the sensors (see
•
note below).
Once completed use the
•
key to cycle through the zone
and check that all signals are ether ‘Good’ or ‘Strong’. If any
sensors show ‘poor’ re-site to a better position.
If a wireless siren is on the system then you can perform a remote
diagnostic check by selecting [WL Siren Test] in the Diagnostic
menu and pressing
twice.
If you nd a sensor is out of range consider using a MCX-600 L
repeater. When powered via 12VDC this will boost signals
received from transmitters.
8) PowerMax has an onboard voice dialler which optionally,
can be used to contact any number you dene in the event of an
alarm activation or alert.
To enable, whilst in installer mode main menu :-
•
•
until the screen shows [Dene Coms], then press .
Press
•
until [20.Report>PRVT] is shown, then press .
We recommend you press
•
until [All (-op/cl)] is shown.
This reports all alarm and tamper events to the user but not
when the system is armed or disarmed (for information on
the other options consult the programming guide).
Press
•
twice.
Phone numbers can be set in the installer mode (Dene Coms
•
- option 17) or via the user settings
The House Identication is a recorded message played when
PowerMax calls the user to notify them of an alarm.
To record this message ensure you are still in the installer mode:-
Press
•
until ‘Dene Voice’ then press and the screen
will display ‘House Identity’.
To record the message press and hold the [2] button then
•
say the house ID e.g. “Mr & Mrs Smith, Blacksmith Cottage,
Truro.”.
Press [5] to listen to the message you recorded.
•
QuickFit Kit Easy Start Guide

Visonic POWERMAX+ Specifications

General

Type	Wireless Security System
Zones	30
Communication	PSTN
Keypad	Yes
Siren	Built-in
Remote Control	Yes
Wireless Frequency	868 MHz
Keypads	Up to 8
Humidity	Up to 85% non-condensing
