1. Main Components
The main components are:
Figure 1.a
Figure 1.b
A Flowhead
B Touchscreen display
C Micro SD card connector
D On/Off button
E Printer door release button
F Printer
G USB connector
H Ethernet connector
I Power supply input
J Flowhead tubing connector (device)
K Flowhead tubing connector (owhead)
