Seat lock
Fig 12. Folded stroller Fig 13. Seat lock closeup
• Into unfolded stroller corpus, attach wheels.
• Front wheel stem slip in the wheel grip in the direction from the bottom to the top, to
the point hearable click.
• To remove the front wheels, press button located at the top of wheel handle and pull it
in from top to bottom (Fig. 12.).
• Rear wheels slide on the pin located in the back of the stroller corpus. Press in this
same time the button located in the central part of the wheel to hearable click.
• To remove the rear wheels, press the button in the middle of the wheel and then pull
the wheel out of the stroller corpus (Fig. 13.).
• Basket for small items should be mounted on the front of the stroller to a thin rod in
the lower part of the side frames using latch, while at the rear of the horizontal rod using
Velcro (Fig 13.).
