Footrest locks closeup
MODEL: JUNIOR
PLUS 2 & 3
LANGUAGE: ENGLISH VERSION: 2022-01
VITEACARE.COM 17
FOOTREST POSITION ADJUSTMENT
• By pressing by both sides of the footrest adjustment button, you can change its position up
or down (Fig. 24.).
• It is important that the regulation buttons are pressed by thumbs, while the rest of the
hand, grasps the footrest frame.
Regulation button
Fig 23. Footrest regulation scheme
Footrest frame
SEAT DEPTH ADJUSTMENT
• Six knobs are located under the seat.
• Their use has been shown on figure 25.
• To adjust the seat depth, loosen the two knobs the seat depth adjustable.
• Grab the seat edge by hand, push or pull to set the desired depth.
• Then tighten the two knobs to adjust the seat depth to prevent automatic changes the
depth of the seat.
Seat depth
adjustable knobs
Side stabilizers
with adjustable
knobs
Side stabilizers with adjustable knobs
Fig 24. Seat depth adjustment
