8. Electronic function
8.1 Abbreviation
T1: Indoor ambient temperature
T2: Coil temperature of indoor heat exchanger
T3: Coil temperature of outdoor heat exchanger
T4: Outdoor ambient temperature
T5: Compressor discharge temperature
8.2 Display function
8.2.1 Icon explanation on indoor display board.
① Auto indicator
This indicator illuminates when the air conditioner is in AUTO
operation.
② Timer indicator
This indicator illuminates when TIMER is set ON/OFF.
③ PRE.-DEF. Indicator (For Cooling & Heating models only)
This indicator illuminates when the air conditioner starts defrosting
automatically or when the warm air
control feature is activated in heating mode.
④ OPERATION indicator
This indicator illuminates when the air conditioner is running.
