AUTO COOL DRY HEAT FAN
TEMP
CLOCK
TIMER ON
TIMER OFF
SPEED
AUTO LOW MED HIGH
MODE
ON
OFF
TEMP
FAN
SPEED
AIR
DIRECTION
SWING
CLOCK
ECONOMIC
RUNNING
TIMER ON
TIMER OFF
TIME ADJUST
OK
CANCEL
1
2
3
AUTO COOL DRY HEAT FAN
TEMP
CLOCK
TIMER ON
TIMER OFF
SPEED
AUTO LOW MED HIGH
MODE
ON
OFF
TEMP
FAN
SPEED
AIR
DIRECTION
SWING
CLOCK
ECONOMIC
RUNNING
TIMER ON
TIMER OFF
TIME ADJUST
OK
CANCEL
1
2
3
4
COOLING/FAN ONLY OPERATION
DRYING OPERATION
Connect the unit with the power.
The OPERATION lamp on the display panel of the indoor
unit starts flashing.
1. Mode select button (MODE)
Select COOL, HEAT (cooling only type without), or
FAN ONLY
ON/OFF button
Push this button again to stop the air conditioner.
The FAN ONLY mode does not control temperature.
Therefore, perform only steps 1,3, and 4 to select
this mode.
Connect the unit with the power.
The OPERATION lamp on the display panel of the indoor
unit starts flashing.
1. Mode select button (MODE)
Select DRY.
2. Temperature button (TEMP.)
Push the "TEMP." Button.
The fan speed indicator displays AUTO. The Indoor fan
speed will be automatically selected LOW.
3. ON/OFF button
Push this button to start the air conditioner.
The OPERATION lamp on the display panel of the indoor
unit lights, and operation starts after approximately 3 minutes.
ON/OFF button
Push this button again to stop the air conditioner.
2. Temperature button (TEMP.)
Set the desired temperature.
¡£
Cooling 21 C or higher
¡£
Heating 28 C or lower
3. Fan speed button (FAN SPED)
Select any of the "AUTO" "LOW", "MED" and "HIGH"
4. ON/OFF button
Push this button to start the air conditioner.
The OPERATION lamp on the display panel of the indoor
unit lights. The operating mode is selected in accordance
with the room temperature and operation starts after
approximately 3 minutes (If you select FAN ONLY mode,
the unit will start immediately.)
Start
Stop
Start
Stop
8
