Vivax ACP-24CH70AEB Service Manual

Service manual
23
9.3 MSE-24CRN2
cooling mode outdoor temperature(Dry bulb temp)
pressure
indoor
conditions
25℃ 30℃ 35℃ 40℃ 45℃ 50℃
pressure
(kg/cm2)
21℃ D
15℃ W
4.3 4.4 4.5 4.6 4.7 4.8
pressure
(kg/cm2)
24℃ D
17℃ W
4.4 4.6 4.7 4.8 5.0 5.1
pressure
(kg/cm2)
27℃ D
19℃ W
4.6 4.8 5.0 5.1 5.3 5.4
pressure
(kg/cm2)
32℃ D
23℃ W
5.1 5.3 5.4 5.6 5.7 5.9
9.4 ACP-24CH70AEB
cooling mode outdoor temperature(Dry bulb temp)
pressure
indoor
conditions
25℃ 30℃ 35℃ 40℃ 45℃ 50℃
pressure
(kg/cm2)
21℃ D
15℃ W
4.3 4.4 4.5 4.6 4.7 4.8
pressure
(kg/cm2)
24℃ D
17℃ W
4.4 4.6 4.7 4.8 5.0 5.1
pressure
(kg/cm2)
27℃ D
19℃ W
4.6 4.8 5.0 5.1 5.3 5.4
pressure
(kg/cm2)
32℃ D
23℃ W
5.1 5.3 5.4 5.6 5.7 5.9
heating mode outdoor conditions
indoor conditions pressure
12℃ D
11℃ W
7℃ D
6℃ W
0℃ D
-1℃ W
(-4℃ D)
(-6℃ W)
(-7℃ D)
(-9℃ W)
(-15℃ D)
(-x℃ W)
15℃
pressure
(kg/cm2)
22.4 20.0 18.9 17.1 16.3 /
18℃
pressure
(kg/cm2)
23.4 21.3 20.4 18.9 17.6 /
20℃
pressure
(kg/cm2)
23.9 22.4 21.3 19.7 18.2 /
22℃
pressure
(kg/cm2)
24.2 23.0 22.0 20.8 19.0 /
