Vivax ACP-24CH70AEB Service Manual

Service manual
24
9.5 MSE-28CRN2
cooling mode outdoor temperature(Dry bulb temp)
pressure
indoor
conditions
25℃ 30℃ 35℃ 40℃ 45℃ 50℃
pressure
(kg/cm2)
21℃ D
15℃ W
4.1 4.2 4.3 4.5 4.6 4.7
pressure
(kg/cm2)
24℃ D
17℃ W
4.3 4.5 4.6 4.8 4.9 5.1
pressure
(kg/cm2)
27℃ D
19℃ W
4.6 4.8 5.0 5.1 5.2 5.4
pressure
(kg/cm2)
32℃ D
23℃ W
5.0 5.2 5.4 5.6 5.7 5.9
9.6 MSE-28HRN2
cooling mode outdoor temperature(Dry bulb temp)
pressure
indoor
conditions
25℃ 30℃ 35℃ 40℃ 45℃ 50℃
pressure
(kg/cm2)
21℃ D
15℃ W
4.1 4.2 4.3 4.5 4.6 4.7
pressure
(kg/cm2)
24℃ D
17℃ W
4.3 4.5 4.6 4.8 4.9 5.1
pressure
(kg/cm2)
27℃ D
19℃ W
4.6 4.8 5.0 5.1 5.2 5.4
pressure
(kg/cm2)
32℃ D
23℃ W
5.0 5.2 5.4 5.6 5.7 5.9
heating mode outdoor conditions
indoor conditions pressure
12℃ D
11℃ W
7℃ D
6℃ W
0℃ D
-1℃ W
(-4℃ D)
(-6℃ W)
(-7℃ D)
(-9℃ W)
(-15℃ D)
(-x℃ W)
15℃
pressure
(kg/cm2)
20.6 19.1 18.3 17.0 16.4 /
18℃
pressure
(kg/cm2)
21.6 20.0 19.1 18.2 17.5 /
20℃
pressure
(kg/cm2)
22.1 21.2 20.0 19.1 18.6 /
22℃
pressure
(kg/cm2)
22.4 21.9 20.8 19.9 19.0 /
