Service manual
27
10.5 MSE-28CRN2
SUMMER OUTDOOR TEMPERATURE DRY
Indoor Conditions 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
Total capacity kW 7.77 7.45 7.01 6.54 6.10 5.77
Sensitive capacity kW 5.81 5.67 5.48 5.26 5.05 4.89
21ºC D
15ºC W
Input kW. 2.70 2.90 3.11 3.35 3.53 3.75
Total capacity kW 8.24 7.93 7.55 7.14 6.75 6.42
Sensitive capacity kW 6.09 5.95 5.78 5.61 5.48 5.43
24ºC D
17ºC W
Input kW. 2.70 2.92 3.15 3.38 3.61 3.84
Total capacity kW 8.74 8.60 8.20 7.65 7.07 6.57
Sensitive capacity kW 6.50 6.39 6.32 5.95 5.71 5.50
27ºC D
19ºC W
Input kW. 2.74 2.98
3.20 3.45 3.69 3.92
Total capacity kW 9.18 9.00 8.89 8.62 8.28 7.93
Sensitive capacity kW 6.44 6.29 6.24 6.16 6.10 6.02
32ºC D
23ºC W
Input kW. 2.81 2.99 3.27 3.55 3.82 4.10
10.6 MSE-28HRN2
SUMMER OUTDOOR TEMPERATURE DRY
Indoor Conditions 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
Total capacity kW 7.77 7.45 7.01 6.54 6.10 5.77
Sensitive capacity kW 5.81 5.67 5.48 5.26 5.05 4.89
21ºC D
15ºC W
Input kW. 2.70 2.90 3.11 3.35 3.53 3.75
Total capacity kW 8.24 7.93 7.55 7.14 6.75 6.42
Sensitive capacity kW 6.09 5.95 5.78 5.61 5.48 5.43
24ºC D
17ºC W
Input kW. 2.70 2.92 3.15 3.38 3.61 3.84
Total capacity kW 8.74 8.60 8.20 7.65 7.07 6.57
Sensitive capacity kW 6.50 6.39 6.32 5.95 5.71 5.50
27ºC D
19ºC W
Input kW. 2.74 2.98
3.20 3.45 3.69 3.92
Total capacity kW 9.18 9.00 8.89 8.62 8.28 7.93
Sensitive capacity kW 6.44 6.29 6.24 6.16 6.10 6.12
32ºC D
23ºC W
Input kW. 2.81 2.99 3.27 3.55 3.82 4.10
WINTER OUTDOOR CONDITIONS
Indoor Conditions
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-8ºC W
Capacity kW 10.46 9.44 8.49 5.91 5.14 5.01
15ºC
Input kW. 3.47 3.11 2.80 2.43 2.26 2.13
Capacity kW 9.92 9.02 8.25 5.68 5.33 4.96
18ºC
Input kW. 3.55 3.11 2.85 2.58 2.49 2.17
Capacity kW 9.88 9.10 8.20 5.45 5.15 4.94
20ºC
Input kW. 3.65
3.20 2.91 2.58 2.50 2.20
Capacity kW 9.27 8.88 7.87 4.81 5.06 4.88
22ºC
Input kW. 3.68 3.40 3.22 2.87 2.66 2.53
