Vivotek FD8166A-N User Manual

VIVOTEK
User's Manual - 9
8. There is a tilt adjustment screw near the lens module. Use a #0, #1, or #2 Phillips
screwdriver to turn the screw and the lens will move upwards or downwards.
WARNING!
Do not use your hands to tune the lens module's tilt angle. Doing so will damage the
delicate tilt mechanism.
Lens UP Lens DOWN

Vivotek FD8166A-N Specifications

General

Brand	Vivotek
Model	FD8166A-N
Category	Security Camera
Language	English
