Vivotek FD8166A-N User Manual

VIVOTEK
6 - User's Manual
Hardware Installation
0002D10766AD
XXXXXX
1. Jot down the camera's MAC address for later reference.
1
2
Semi-circular
cut-out
Slide cover
Release tab
1. Use one hand to hold the camera
bottom and another hand to hold the
dome cover. Press the release button.
2. Remove the dome cover.
3. Remove the slide cover if you want to
route cables from the side of camera
instead of a hole on the ceiling or wall.
Remove the strain relief boot if your
Ethernet cable comes with one.

Vivotek FD8166A-N Specifications

General

Brand	Vivotek
Model	FD8166A-N
Category	Security Camera
Language	English
