Vivotek FD8168 User Manual

VIVOTEK
6 - User's Manual
Physical Description
Reset button
Microphone
Lens
Lens retention screw
MicroSD card slot
Status LED
Quick Installation Guide
Before you begin:
You can connect the Ethernet cable to a PC or laptop for a live
view. (See page 10). Raise the camera to the estimated position,
and evaluate the eld of view by turning the mount bracket and
lens.
Shooting
direction
Loosen the retention screw to change
shooting angle.
1. The camera can only be powered by Power over Ethernet (PoE).
2. The camera can only be installed in an indoor environment.
NOTE:
