Vivotek FD8361L - Page 126

VIVOTEK
126 - User's Manual
win_i<0~2>_name string[14] 4/4 Name of motion window 1~3.
win_i<0~2>_left 0 ~ 320 4/4 Left coordinate of window position.
win_i<0~2>_top 0 ~ 240 4/4 Top coordinate of window position.
win_i<0~2>_width 0 ~ 320 4/4 Width of motion detection window.
win_i<0~2>_height 0 ~ 240 4/4 Height of motion detection window.
win_i<0~2>_objsize 0 ~ 100 4/4 Percent of motion detection window.
win_i<0~2>_sensitivity 0 ~ 100 4/4 Sensitivity of motion detection window.
profile_i<0~(m-1)>_enable <boolean> 4/4 Enable profile 1 ~ (m-1).
profile_i<0~(m-1)>_policy day,
night,
schedule
4/4 The mode which the profile is applied to.
profile_i<0~(m-1)>_begintim
e
hh:mm 4/4 Begin time of schedule mode.
profile_i<0~(m-1)>_endtime hh:mm 4/4 End time of schedule mode.
profile_i<0~(m-1)>_win_i<0
~2>_enable
<boolean> 4/4 Enable motion window.
profile_i<0~(m-1)>_win_i<0
~2>_name
string[14] 4/4 Name of motion window.
profile_i<0~(m-1)>_win_i<0
~2>_left
0 ~ 320 4/4 Left coordinate of window position.
profile_i<0~(m-1)>_win_i<0
~2>_top
0 ~ 240 4/4 Top coordinate of window position.
profile_i<0~(m-1)>_win_i<0
~2>_width
0 ~ 320 4/4 Width of motion detection window.
profile_i<0~(m-1)>_win_i<0
~2>_height
0 ~ 240 4/4 Height of motion detection window.
profile_i<0~(m-1)>_win_i<0
~2>_objsize
0 ~ 100 4/4 Percent of motion detection window.
profile_i<0~(m-1)>_win_i<0
~2>_sensitivity
0 ~ 100 4/4 Sensitivity of motion detection window.
Group: tampering_c<0~(n-1)> for n channel product
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable or disable tamper detection.
threshold 0 ~ 255 4/4 Threshold of tamper detection.
duration 10 ~ 600 4/4 If tampering value exceeds the ‘threshold’ for more
than ‘duration’, then tamper detection is triggered.
