Vivotek FD8367A-V - Technical Specifications

VIVOTEK
320 - User's Manual
Technical Specications
Model FD8367A-V
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/2.9" Progressive CMOS
Maximum Resolution 1920x1080 (2MP)
Lens Type Vari-focal, Manual
Focal Length f = 2.8 ~12mm
Aperture F1.4~F2.4
Auto-iris DC-iris
Field of View
33.1°~96.6° (Horizontal)
18.9°~53.4° (Vertical)
35.3°~101.9° (Diagonal)
ShutterTime 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Enhanced
Day/Night Removable IR-cut filter for day & nig
ht function
Minimum Illumination
0.05 Lux @ F1.4 (Color)
0.01 Lux @ F1.4 (B/W)
Pan/Tilt/Zoom Functionalities
ePTZ:
48x digitalzoom (4x on IE plug-in, 12x built-in)
IR Illuminators
Built-in IR illuminators, effective up to 30 meters
with Smart IR
IR LED*8
On-board Storage
MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.264 & MJPEG
Maximum Frame Rate
30 fps @ 1920x1080
In both compression modes
Maximum Streams 4 simultaneous streams
S/N Ratio 70.9 dB
Dynamic Range 69.4 dB
V
ideo Streaming
Adjustable resolution, quality and bitrate
Smart Stream II
Image Settings
Time stamp, text overlay,flip & mirror
Configurable brightness, contrast, saturation,
sharpness, white balance, exposure control, gain,
backlight compensation, privacy masks
Scheduled profile settings, 3D noisereduction,
video rotation, defog
Network
Users Live viewing forup to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS,
PPP
oE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL,
TLS
Interface
10 Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e
& CAT6 cables which are compliant withthe 3P/ETL
standard.
Technical Specifications
Compatible Accessories
ONVIF Supported, specification available at www.onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
Alarm and Event
Alarm Triggers
Motiondetection, manual trigger, periodical
trigger, system boot, recording notification, camera
tampering detection
Alarm Events
Event notification usingHTTP, SMTP, FTP and NAS
server, SD Card
File upload via HTTP, SMTP, FTP, NAS server and SD
card
General
Connectors RJ-45 for Network/PoE connection
LED Indicator System p
ower and statusindicator
Power Input IEEE 802.3af PoE Class 0
Power Consumption Max: 10.5 W
Dimensions Ø: 129 mm x 93 mm
Weight Net: 590.6 g
Casing
Weather-proof IP66-rated housing
Vandal-proof IK10-rated housing
Safety Certifications CE, LVD, FCC Class A, VCCI, C-Tick
Operating Temperature
Starting Temperature: -10°C ~ 50°C (14°F~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F~ 122°F)
Humidity 90%
Warranty 36 months
System Requirements
Operating System Microsoft Windows 8/7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~43 (streamingonly)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
Others
Quickinstallation guide, alignment sticker, screw
pack
Dimensions
Ø129 mm
93 mm
Mounting Kits
AM-21A
L-shape Bracket
(Coming Soon)
AM-528
Mounting Adapter
AM-51D
Adapter Ring
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Ver. 5
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. T: +886-2-82455282 F: +886-2-82455532 E: sales@vivotek.com W: www.vivotek.com
VIVOTEK INC.
