VIVOTEK
204 - User's Manual
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable motion detection window.
name string[14] 4/4 Name of motion window.
polygonstd 0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999
4/4 Coordinate of polygon window position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_motion_wintype" = polygon.
* Only available when std is listed in
"capability_motion_windomain
objsize 1 ~ 100 4/4 Percent of motion detection window.
sensitivity
<Not recommended to use
this>
1 ~ 100 4/4 Sensitivity of motion detection window.

* We replace "sensitivity" with
"win_sensitivity".
* This parameter will not be used after the
version number (httpversion) is equal or
greater than 0400a.
polygonpx
<Not recommended to use
this>
0 ~ W,0 ~ H, 0 ~
W,0 ~ H, 0 ~ W,0 ~
H, 0 ~ W,0 ~ H
W: 0~ The current
image width -1
H: 0~ The current
image height -1
4/4 Coordinate of polygon window position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)

* Only available when
"capability_motion_wintype" = polygon.
* Only available when px is listed in
"capability_motion_windomain
* It's recommended to use polygonsd
* This parameter will not be used after the
version number (httpversion) is equal or
greater than 0400a.
polygon
<Not recommended to use
this>
0 ~ 320,0 ~ 240, 0
~ 320,0 ~ 240, 0 ~
320,0 ~ 240, 0 ~
320,0 ~ 240
4/4 Coordinate of polygon window position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_motion_wintype" = polygon.
* Only available when qvga is listed in
"capability_motion_windomain
