VIVOTEK
14 - User's Manual
Micro B
converter
WiFi dongle
64
GB
10
I
1
21
11. If preferred, install a MicroSD card to the camera. You can connect a WiFi dongle to the
camera's micro USB port for an onsite adjustment of imaging and the shooting direction.
You can use a notebook to connect the camera at the installation site.
Refer to Step 21.
icro
icro
DI-: Yellow
DI1+: Blue
DO1-: Orange
DO+(12V): Brown
A
Extension I/O kit
12. Below are the pinouts of the I/O combo cable. If you prefer more audio, DC, and I/
O connections, you can purchase and install an extension kit. Refer to the installation
option A section for more information.
To Next Page
