User's Manual - 59
Media > Video
Stream settings
This Network Camera supports multiple streams with frame size ranging from 176 x 144 to 1280 x
800 pixels.
The denition of multiple streams:
■ Stream 1: Users can dene the "Region of Interest" (viewing region) and the "Output Frame Size"
(size of the live view window).
■ Stream 2: The default frame size for Stream 2 is set to the minimized 640 x 360 for viewing on
mobile devices.
■ Stream 3: Stream 3 does not support the "Region of Interest" conguration.
Click Viewing Window to open the viewing region settings page. On this page, you can set the
Region of Interest and the Output Frame Size for streams 1 and 2.
Please follow the steps below to set up those settings for a stream:
1. Select a stream for which you want to set up the viewing region.
2. Select a Region of Interest from the drop-down list. The floating frame, the same as the
one in the Gloabl View window on the home page, will resize accordingly. If you want to set
up a customized viewing region, you can also resize and drag the oating frame to a desired
position with your mouse.
3. Choose a proper Output Frame Size from the drop-down list according to the size of your
monitoring device.
