Vivotek FD9371-HTV User Manual

VIVOTEK
2 - User's Manual
Table of Contents
Overview
..............................................................................................................................................................
3
Revision History ...............................................................................................................................................3
Read Before Use ..............................................................................................................................................4
Package Contents ............................................................................................................................................4
Symbols and Statements in this Document ...................................................................................................... 5
Physical Description .........................................................................................................................................5
Hardware Installation ........................................................................................................................................ 6
Network Deployment ......................................................................................................................................17
Software Installation .......................................................................................................................................20
Ready to Use .................................................................................................................................................. 21
Accessing the Network Camera
....................................................................................................................
22
Using Web Browsers ......................................................................................................................................22
Using RTSP Players ....................................................................................................................................... 25
Using 3GPP-compatible Mobile Devices ........................................................................................................ 26
Using VIVOTEK Recording Software .............................................................................................................27
Main Page
.........................................................................................................................................................
28
Client Settings
..................................................................................................................................................
33
Conguration
....................................................................................................................................................
38
System > General settings .............................................................................................................................39
System > Homepage layout ..........................................................................................................................41
System > Logs ...............................................................................................................................................44
System > Parameters .................................................................................................................................... 46
System > Maintenance ................................................................................................................................... 47
Media > Image .............................................................................................................................................51
Media > Video ................................................................................................................................................64
Media > Video ................................................................................................................................................65
Media > Audio.................................................................................................................................................72
Network > General settings ............................................................................................................................73
Network > Streaming protocols ....................................................................................................................81
Network > SNMP (Simple Network Management Protocol) ...........................................................................90
Security > User accounts ...............................................................................................................................91
Security > HTTPS (Hypertext Transfer Protocol over SSL) .................................................................92
Security > Access List ..................................................................................................................................99
PTZ > PTZ settings ......................................................................................................................................104
Event > Event settings..................................................................................................................................108
Applications > Motion detection....................................................................................................................122
Applications > DI and DO ...........................................................................................................................125
Applications > Tampering detection ............................................................................................................. 126
Applications > Audio detection ...................................................................................................................127
Applications > Package management - a.k.a., VADP (VIVOTEK Application Development Platform) .......129
Recording > Recording settings ..................................................................................................................132
Local storage > SD card management ......................................................................................................... 137
Local storage > Content management .........................................................................................................138
Appendix
........................................................................................................................................................
141

Vivotek FD9371-HTV Specifications

General

Type	-
PTZ control	Yes
Certification	CE, LVD, FCC Class A, VCCI, C-Tick, UL
Placement supported	Outdoor
Flash memory	128 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Sensor type	CMOS
Optical sensor size	1/2.8 \
Video streaming	Adjustable resolution, quality and bitrate Smart Stream II
Total megapixels	3 MP
Maximum resolution	2048 x 1536 pixels
Video formats supported	H.264, H.265, M-JPEG
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Supported graphics resolutions	2048 x 1536 (QXGA)
Digital zoom	48 x
Focal length range	3 - 9 mm
Maximum aperture number	2.3
Number of cameras	1
Camera shutter speed	1/5 - 1/16000 s
Minimum illumination	0.001 lx
LED type	IR
Night vision distance	30 m
Audio system	2-way
Audio formats supported	G.711
Signal-to-Noise Ratio (SNR)	43 dB
DC output voltage	12
Power source type	PoE
Power consumption (max)	12 W
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
LED indicators	Power, Status
Housing material	Metal
Protection features	Vandal proof
International Protection (IP) code	IP66
Browser supported	Mozilla Firefox 7~43 (streaming only) Internet Explorer 7/8/9/10/11
Number of users	10 user(s)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS
Interface	RJ-45
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Height	103 mm
Weight	927 g
Diameter	155 mm
