EN - 2
Physical Description
2
Inner View
Header (J7)
Spring Contacts
(A)
Lens
Contacts for Internal Microphone
(B)
Header (J6)
Ethernet 10/100 RJ45 Socket
MicroSD/SDHC/SDXC Card Slot
Reset Button
Status LEDs
Cabling Cutout
