EN - 2
Physical Description
2
Inner View
Header (J7)
Contacts (A)
Lens
Header (J6)
Ethernet 10/100 RJ45 Socket
i
Align (B) to (A) when
attaching the dome cover
MicroSD/SDHC/SDXC Card Slot
Reset Button
Status LEDs
Contacts for IR units (B)
