Vivotek IB8367A User Manual

VIVOTEK
User's Manual - 133
Search Results
The following is an example of search results. There are four columns: Trigger time, Media type,
Trigger type, and Locked. Click
to sort the search results in either direction.
Numbers of entries displayed
on one page
Click to open a live view
■ Play: Click on a search result which will highlight the selected item. A Play window will appear on
top for immediate review of the selected le.
For example:
■ Download: Click on a search result to highlight the selected item in purple as shown above. Then
click the Download button and a le download window will pop up for you to save the le.
■ JPEGs to AVI: This functions only applies to “JPEG“ format files such as snapshots. You can
select several snapshots from the list, then click this button. Those snapshots will be converted
into an AVI le.

Vivotek IB8367A Specifications

General

Weather Resistance	IP66
Vandal Resistance	IK10
Maximum Resolution	1920x1080
Lens Type	Varifocal
Focal Length	2.8mm ~ 12mm
Aperture	F1.4
Day/Night	Yes
IR Illuminators	Built-in, up to 30m
Minimum Illumination	0.05 Lux
Video Compression	H.264, MJPEG
Maximum Frame Rate	30 fps
Supported Protocols	IPv4, IPv6, TCP, UDP, HTTP, HTTPS, RTSP, RTP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPnP, SNMP, 802.1X
Ethernet	10/100Base-TX
Power Supply	12V DC
Operating Temperature	50°C
Image Sensor	1/2.8" Progressive Scan CMOS
