7.11 Image setting per channel
Group: image_c<0~(n-1)> for n channel profucts and m profile
n denotes the value of "capability_nvideoin" and m denotes the value of "capability_nvideoinprofile"
NAME VALUE SECURITY
(get/set)
DESCRIPTION
brightness
<Not recommended to use this>
-5~5,100 4/4 -5: Darker <-> 5: Bright
100: Use " image_c<n>_brightnesspercent"
* Only available when bit 0 of
"capability_image_c<n>_basicsetting" is 1
* We replace "brightness" with
"brightnesspercent".
* This parameter will not be used after the
version number (httpversion) is equal or
greater than 0400a.
contrast
<Not recommended to use this>
-5~5,100 4/4 -5: Less contrast <-> 5: More contrast
100: Use " image_c<n>_contrastpercent"
* Only available when bit 1 of
"capability_image_c<n>_basicsetting" is 1.
* We replace "contrast" with "contrastpercent
".
* This parameter will not be used after the
version number (httpversion) is equal or
greater than 0400a.
saturation
<Not recommended to use this>
-5~5,100 4/4 -5: Less saturation <-> 5: More saturation
100: Use " image_c<n>_saturationpercent"
* Only available when bit 2 of
"capability_image_c<n>_basicsetting" is 1.
* We replace "saturation" with
"saturationpercent".
* This parameter will not be used after the
version number (httpversion) is equal or
greater than 0400a.
