Package Contents
■ IB836BA-HT, IB836BA-EHT, IB836BA-HF3, or IB836BA-EHF3.
■ L-type T8 anti-tamper key wrench, desiccant bag, screws
■ Waterproof Ethernet cable housing
■ Software CD
■ Sun shield
■ Quick Installation Guide & alignment sticker
* T8 key wrench is also used for the hex socket screw on the camera bracket.
Read Before Use
The use of surveillance devices may be prohibited by law in your country. The Network Camera
is not only a high-performance web-ready camera but can also be part of a exible surveillance
system. It is the user’s responsibility to ensure that the operation of such devices is legal before
installing this unit for its intended use.
It is important to first verify that all contents received are complete according to the Package
Contents listed below. Take note of the warnings in the Quick Installation Guide before the Network
Camera is installed; then carefully read and follow the instructions in the Installation chapter to
avoid damage due to faulty assembly and installation. This also ensures the product is used
properly as intended.
The Network Camera is a network device and its use should be straightforward for those who
have basic networking knowledge. It is designed for various applications including video sharing,
general security/surveillance, etc. The Configuration chapter suggests ways to best utilize the
Network Camera and ensure proper operations. For creative and professional developers, the URL
Commands of the Network Camera section serves as a helpful reference to customizing existing
homepages or integrating with the current web server.
Mounting Hole Positions
AA
AA
BBBB
A_117.4
0
-0.5
B_117.4
0
-0.5
3-
6.5 ± 0.1
5
86
0
-0.4
86
0
-0.4
10.52
10.49
0
-0.15
21
+0.2
0
48.53
0
-0.2
5
SECTION BB-BB
Dimensions are measured
in millimeters.
